The most rapid 360° jaundice treatment all around the baby
For all thermally stable babies weighing <5 kg
Luminous Flux >5mW/cm² (>78 μW/cm²/nm) per hood
16 blue light treatment tubes targeted on the bilirubin degradation spectrum
Limits mother/baby separation time
Quiet mode : visual alarm before audible alarm to avoid stress to baby
Orange-tinted monitoring window to reduce dazzle effects
Timer for setting the exposure time : switches off automatically
Pause key to suspend treatment if necessary
Automatic treatment suspension if hammock is removed to access the baby
Manoeuvrable from one department to another : easy to move with a handle, 4 casters and a surrounding bumper rail
Practical storage areas for easy access to accessories : upper shelf, drawer, accessory holder rail, control screen
Incomparable efficacy, rapid and intensive treatment
The O’bloo 360° phototherapy cradle is ideal for severe jaundice, making it possible to avoid the need for blood exchange transfusions and reducing the separation time from parents. Equipped with 16 blue treatment tubes placed in 2 semi-cylindrical sections, this cradle developed by médipréma enables uniform exposure to light over the whole body surface of the baby. It offers optimal exposure of > 5 mW/cm2 (>78 μw/cm²/nm) per semi-cylindrical section.
An ergonomic cradle that does not compromise the baby’s comfort and safety
Médipréma’s O’bloo 360° phototherapy cradle facilitates the work of medical teams. Thanks to its fold-down screens, it enables easy access to the baby. The screens present on the 4 sides of the device prevent light disturbance for nursing staff.
Intuitive and easy to use, it has a control unit with LCD screen placed at eye level that facilitates programming of exposure time thanks to an hour counter. A pause button is also available to suspend treatment during baby care procedures.
In addition to its ergonomic aspect, the O’bloo 360° cradle also optimises the safety of the infant, ensuring monitoring of the temperature inside the canopy and monitoring the baby’s skin temperature, with upper and lower visual and sound alarms to prevent any risk of hypo or hyperthermia. SpO2 and pulse measurement are available as optional extras.
Throughout treatment, the baby is placed in a hammock for optimal comfort.
Protective screens ensure the baby’s safety and side windows enable total monitoring.
16 BLUE LIGHT TREATMENT TUBES placed inside 2 semi-cylin-drical hoods.
The upper hood is mounted on a vertical slide bar raised on a jack which enables the operator to move it up and down (up to 330mm).
CONTROL BOX with a LCD display at eyes-level to allow a good visibility of parameters and alarms
MONITORING AND ACCESS TO THE INFANT :
AMBIENT TEMPERATURE REGULATION :
BABY SKIN TEMPERATURE MONITORING : The high and low alarms combine visual and sound alarms to prevent any risk of hypothermia and hyperthermia
SHELF and DRAWER
Standardized rail around the unit for accessories attachment
MOVING WITH EASE :
SOUND LEVEL : <50d(B)A
ABSORBED POWER : 1000VA
POWER SUPPLY : 220-240V / 50Hz (115V-60Hz and 220V-60Hz in option)
ELECTRICAL CLASSIFICATION : Ib
DIMENSIONS (LxWxH) : 880x650x1440mm
WEIGHT : 61kg
Class IIa medical device
Electrical class Ib
